HVG Series     65~1000W Constant Voltage + Constant Current LED Driver      WWW.CYNOPOWER.COM

■ Features                                                                          ■ Applications

‧ Wide input range 180~528VAC                                                                                   ‧ LED greenhouse lighting

‧ Constant Voltage + Constant Current mode output                                                 ‧ LED statium lighting

‧ Metal housing with Class I design                                                                               ‧ LED mining lighting

‧ Built-in active PFC function                                                                                          ‧ Type“HL" for use in Class l, Division 2hazardous(Classified)location

‧ 1P67/lP65 rating for indoor or outdoor installations

‧ Function options: output adjustable via potentiometer,3 in 1 dimming (dim-to-off);Smart timer dimming

‧ Typical lifetime>50000 hours

‧ 5 years warranty

■ Description

HVG-480 series is a 480W AC/DC LED driver featuring dual-mode constant voltage and constant current output. HVG-480 operates from 180~528VAC and offers models with different rated voltages ranging between 24V and 54V. Thanks to the high efficiency of up to 95% and the fanless design, the entire series is able to operate at -40°C~+85°C case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HVG-480 is equipped with various function options, such as dimming methodologies, to provide optimal design flexibility for LED lighting systems.
